: Diaphragm

Service intended

P750 series have diaphragm seal to be combined with a pressure gauge. These series are suitable to be used for the situation where corrosive, contaminated, hot, and viscous pressure mediums are present, and it could be used for a chemical, food, beverage, biochemical, and pharmaceutical industry.

Nominal diameter	63, 80 and 100 mm
Accuracy	63 and 80 mm : ±1.6 % of full scale 100 mm : ±1.0 % of full scale
Pressure range (MPa, kPa, bar)	Steady : 75 % of full scale (63 and 80 mm) 100 % of full scale (100 mm) Over range protection : 130 % of full scale
Working pressure	Steady : 75 % of full scale Over range protection : 130 % of full scale
Working temperature	Ambient : -20 ~ 65 °C Fluid : Max. 121 °C
Temperature effect	Accuracy at temperature above and below the reference temperature (20 ℃) will be effected by approximately ±0.5 % per 10 ℃ of full scale

Standard features

Process connection	316SS P751 : 1½" and 2" Nut P752 : 1", 1½", 2", clamp connection P753 : PF¾", PF1", PF1½", male screw P754 : Standard and non standard flange P755 : Homogenizer P756 : Homogenizer flange (95 x 43 x 28 mm)
Body	Stainless steel (316SS)
Diaphragm	Stainless steel (316L SS) Electropolished diaphragm Surface roughness : ≤ Ra : 0.8 ㎛
System filling	Food grade oil (FDA certified)
Certificates	ATEX II 2G Ex h IIC T6...T1 Gb ATEX II 2D Ex h IIIC T85°C....T450°C Db

Download

Certificates

타이틀

P750 Series_Sanitary pressure gauge

P750 Series (P751, P752, P753, P754, P755, P756)
