Service intended

The high performance pressure transmitter SMT2002 is suitable to measure liquid, gas, or steam flow as well as liquid level, density and pressure.
The key features include quick response, remote set-up using communications, self-diagnostics and optional status output for pressure high/low alarm.

Standard features

Accuracy	±0.05 % of calibrated span. ±0.075 % of calibrated span.
Range limits	6 kPa ~ 40 MPa
Turn down	Adjustable up to 100:1 range ability
Temperature compensation	High sensitivity temperature sensor packaged in the sensor
Isolating diaphragm	316L SS Hastelloy C 316L SS with Gold Plated
Measurement medium	Gas, steam and liquid
Stability	10 years stability 0.15 % of URL
Output	4 ~ 20 mA with HART protocol
Degree of protection	EN60529/IEC529/IP66 EN60529/IEC529/IP67
