| Pressure connection |
Stainless steel (316SS) |
| Element |
Stainless steel (316SS),
Model : P2584 (100 mm) and P2586 (160 mm)
<10 MPa : C type bourdon tube
≥10 MPa : Helical type bourdon tube
Model : P2582 (63 mm) and P2583 (80 mm)
<6 MPa : C type bourdon tube
≥6 MPa : Helical type bourdon tube |
| Blowout protection |
Back, Rubber disc for 80, 100 and 160 mm
Top, Rubber disc for 63 mm |
| Case |
Stainless steel (304SS) |
| Cover |
Stainless steel (304SS) Bayonet type |
| Window |
Laminated safety glass |
| Movement |
Stainless steel |
| Dial |
White aluminium with black graduations |
| Pointer |
Black painted aluminium alloy |
| Process connection |
63 mm : ⅛", ¼" PT, NPT and PF
80 mm : ¼", ⅜" PT, NPT and PF
100 and 160 mm : ¼", ⅜", ½" PT, NPT and PF |
| Certificates |
Pressure equipment directive (2014/68/EU)-Annex III Module H
ATEX II 2G Ex h IIC T6...T1 Gb
ATEX II 2D Ex h IIIC T85°C....T450°C Db |
| Option |
- Zero adjustable pointer
(Only available with diameter 100 and 160 mm)
- Zero adjustment (External) : 100 and 160 mm
- Pressure connection and element : Monel
(Only available with diameter 100 and 160 mm)
- Silicone filling
- Maximum Pointer
(Not applicable to 3 bar, Only available with diameter
100 mm)
|
